The PSGA series of
cast aluminium are a ruggard (IK08) wall mounted
electrical terminal / Junction box which have a texture powder
coated RAL 7011 finish.
They are rated to IP 66 / Nema 4 and have UL & cUL approvals. Cast aluminium provides an optimum corrosion
resistance and can typically be found in harsh / outdoor environments.
They exibit an excellent performance of strength, heat transfer
/release, and are water / dust proof when installed acording to
manufacturers instructions.
PSGA Series
- IP66Cast Aluminium
Terminal / Junction Boxes
16
Models, RAL 7001
150
x 150 x 95 ~ 600 x 400 x 135
Supply includes:
Terminal Box with cover,
captive cover screws, Screws foa attaching support rails, Screws for
earth connection.
Available accessories include:
Wall mounting Brackets, 2mm Gal mounting plates*,
hinges*
